HOTA D6 Pro - Page 16

Working Parameters Display
Operation and Setup
13
D6 Pro AC/DC Dual Channel Smart Charger
Current
Total Battery
Voltage
Standby...
1
4
2
5
3
6
Task Status
Current
Channel
Present
Current
Capacity
Charged
Operation
Time
Device Name
Standby
Cell Voltage
Standby State Simple Operation
1. Connect power supply to the AC or DC port of the charger, wait for the system
to complete the self-checking. connect the battery to the charger in the
standby interface;
2. The black display in the standby state，at this time the output current, output power,
capacity charged and run time are all zero;
Scroll the speed shuttle key during operation can switch the display information in the lower half of the
screen, which are cell voltage and run data.
3. After select the corresponding channel，Short press the speed shuttle key to pop up
the“Task Settings”menu.
4. Short press CH key display the channel you choose;
5. Long press the speed shuttle key to enter the“Charger Settings”menu.
