HotSpring Aria - Grandee (Model Gg)

x Page x x
15.5" (39.4 cm)
71 " (180.3 cm)
49" (124.5 cm)
3.5" (8.9 cm)
34.5" (87.6 cm)
38" (96.5 cm)
53.5" (135.9 cm) 43" (109.2 cm)
91" (231 cm)
19.5” (49.5 cm)
26.25" (66.7 cm)
19.5” (49.5 cm)
25.5" (64.7 cm)
100" (254 cm)
(Bottom view)
1 3/4” (4.4 cm)
ELECTRICAL CUTOUT
15.5" (39.4 cm)
71 " (180.3 cm)
49" (124.5 cm)
3.5" (8.9 cm)
34.5" (87.6 cm)
38" (96.5 cm)
53.5" (135.9 cm) 43" (109.2 cm)
91" (231 cm)
19.5” (49.5 cm)
26.25" (66.7 cm)
19.5” (49.5 cm)
25.5" (64.7 cm)
100" (254 cm)
GRANDEE (MODEL GG)
Dimensions
NOTE: All dimensions are approximate; measure your spa
before making critical design or pathway decisions.
NOTE: Watkins Manufacturing Corporation requires that the GRANDEE be installed on a minimum 10 cm (4”)
thick reinforced concrete pad or a deck that is able to withstand more than 555 kg/m ² (115 lbs. per square foot).
WARNING: The GRANDEE must not be shimmed in any manner.
DOOR SIDE
UPSIDE DOWN VIEW OF SPA
(Front view)
DOOR
MAIN DRAIN
SECONDARY DRAIN
x Page x x Page 5 Pre-Delivery Instructions
