HotSpring Aria - SOVEREIGN (Model II)

Pre-Delivery Instructions Page 8
SOVEREIGN (Model II)
Dimensions
NOTE: All dimensions are approximate; measure your spa
before making critical design or pathway decisions.
38" (96.5 cm)
18" (45.7 cm)
38" (96.5 cm)
18" (45.7 cm)
80" (203 cm)
93" (236 cm)
23.75" (60.3 cm) 20" (50.8 cm
)
20" (50.8 cm
)
26" (66 cm)
34.5" (87.6 cm)
3.5" (8.9 cm)
29 " (73.6 cm)
33" (83.8 cm)
14.5" (36.8 cm)
60" (152.4 cm)
DOOR
UPSIDE DOWN VIEW OF SPA
DOOR SIDE
•
15 leveling points(place shims at illustrated locations ).
(Front view)
(Bottom view)
1 3/4” (4.4 cm) ELECTRICAL CUTOUT
MAIN DRAIN
SECONDARY DRAIN
