62 " (157.5 cm)
33" (83.8 cm)
21.5" (54.6 cm)
3.5 " (8.9 cm)
32 " (81 cm)
36" (91 cm)
41.5" (105 cm) 41.5" (105 cm)
18" (46 cm)18" (46 cm)
87" (221 cm)
20" (50.8 cm)
26.5" (67.3 cm)
20 " (50.8 cm)
17.25 " (43.8 cm)
87" (221 cm)
1 3/4” (4.4 cm) ELECTRICAL CUTOUT
x Page x x
VANGUARD (Model VV) & ARIA (Model AR)
Dimensions
NOTE: All dimensions are approximate; measure your spa
before making critical design or pathway decisions.
(Front view)
(Bottom view)
Page 7 Pre-Delivery Instructions
•
15 leveling points (place shims at illustrated locations).
DOOR SIDE
UPSIDE DOWN VIEW OF SPA
MAIN DRAIN
SECONDARY DRAIN
DOOR
