97-6642 • HOTSY 781SS, 871SS, 921SS • REV. 7/06
OPERATOR’S MANUAL
PRESSURE WASHER
18
EXPLODED VIEW - PARTS LIST
ITEM PART NO. DESCRIPTION QTY
1 318226 Chassis, Welded Assy 1
375575 Chassis, Weldment (921SS) 1
2 780460 Washer, 5/16" x 1-1/4", Fender, SAE 3
3 952724 Tank, Fuel, 6-Gallon 1
952733 Tank, Fuel, 8 Gal Hotsy (921SS) 1
4 707116 Hose, 1/4", Fuel Line, Green 22"
5 703155 Nut, 5/16", SMAEC, NC (781SS, 871SS) 17
(921SS) 15
6 780452 Washer, 5/16", Flat, SAE (781SS, 871SS) 14
780562 Washer, 3/18", Flat, SAE (921SS) 10
7 859815 Grommet, Rubber, Nozzle Holder 3
8 646113 Label, Detergent Metering 1
9 799484 Nut, 10/32" Keps 4
10 2-010531 Mount Rubber Vibration, 5/16", 70 Duro (781SS, 9871SS) 4
2-010532 Mount Rubber Vibration, 3/8", 70 Dura (921SS) 4
11 834416 Label, Instructions 1
12 860273 Regulator, Voltage, 15 Volt 1
13 357054 Hose, 3/8" Push-on 30"
14 735323 Screw, 10/32" x 3/4" BH SOC CS 4
15 268006 Insulation, Cerafelt 18" x 50" 1
16 226222 Coil, 16" 1
17 780480 Washer, 3/8", Lock Split Ring (921SS) 4
18 375449 Coil, Tank SS, Weldment 1
19 824115 Clip, Retaining, U-Type 4
20 213044 Top Hat, Weld Assy, 16" Hotsy Coil 1
21 268004 Insulation, Cerafelt, 16 OD x 8.3 ID 1
22 860102 Ring, Insulation Retainer, 16" Top Hat 1
23 829979 Label, Plate Aluminum 2
24 10-07993 Label, Warnings 1
25 859806 Grommet, 2-1/8" x 2-7/8" x 7/16" Rubber 1
26 815329 Bushing, 1" Snap 1
27 616000 Bushing, Snap, 5/8" 1
28 698200 Nipple, 1/4" x 2" x 1/2", Brass 1
29 615279 Bushing, 3/8" x 1/4", Galv. 1
30 851080 Filter, Fuel Hotsy, 3/8" Female 1
31 698020 Hose Barb, 1/4" Barb x 1/4" ML Pipe 3
32 823988 Clamp, Hose, UNI .46-.54 ST 4
33 867368 Hose, 1/4", Push-On, Fuel Line 1
34 780456 Washer, 5/8", Flat, SAE 8
35 983013 Wheel & Tire, 6.5" Steel Rim, 12.5" Tire 4
36 817322 Cap, 5/8" Axle Hub, Black 4
37 848616 Nut, .61 ID, Push, Flat 4
38 817312 Cap, w/Fuel Gauge 1
39 661277 Standpipe 1
40 754711 Tee, 3/8" Female 1
