Hotsy 871SS - Exploded View Parts List Continued

97-6642 • HOTSY 781SS, 871SS, 921SS • REV. 7/06
19
PRESSURE WASHER
OPERATOR’S MANUAL
EXPLODED VIEW - PARTS LIST
ITEM PART NO. DESCRIPTION QTY
41 799490 Swivel, 1/4" JIC Fem, Push-On 1
42 815230 Bushing, Rubber, Nitrile 2
43 2-10491 Plug, 1/4" JIC 1
44 213191 Insulation 1
45 615433 Bolt, 5/16" - 24 x 3/4" NF HH 4
46 860282 Reducer, M14 to 1/4" F 1
47 646226 Label, Hot/Caliente w/Arrows Warning 1
48 661278 Engine, 7 HP Robin (871SS) 1
661280 Engine, 6HP Robin (781SS) 1
5-0005 Engine, Robin 9HP (921SS) 1
49 615939 Screw, 5/16" x 1-1/2" Whiz (781SS, 871SS) 2
612985 Bolt, 3/8" x 1-1/2", NC HH (921SS) 4
50 262208 Hose, 3/8" x 22", 1 Wire, Pressure Loop (871SS) 1
4-02047722 Hose, 3/8" x 22" 2-Wire (781SS, 921SS) 1
51 801102 Nipple, 3/8" Hex, Steel 1
52 715744 Plug, 3/8", Sq. Head, Galv. 1
53 926598 Rivet, 1/8" x 1/4", POP, AL 8
54 90-10127 Bolt, 5/16" x 2-3/4" Whiz Loc (781SS, 871SS) 2
444461  Label, Caution, Gasoline, White 1
646026  Label, Warning, Carbon Monoxide 1
834153  Label, Fuel Type 1
834154  Label, Caution Winterize 1
834159  Label, Use Hotsy Detergent 1
646095  Label, Troubleshooting 1
213191  Insulation Pancake, 18" 1
753187  Key, 3/16" x 3/16" x 2" SST 1
890874  Tag, Oil Burner 1
735321  Screw, 4 mm x 6 mm, Pan Head 1
890873  Tab, Gas Engine 1
890769  Warning, Unloader 1
9.800-018.0  Label, Tip Over 1
9.800-049.0  Label, Cleaning Solution 1
55 799515 Nipple, 1/2" JIC x 3/8" Pipe (781SS, 921SS) 1
 Not Shown
