24 Chapter 2 D82008753R 10/15
• ONLY USE to charge AGM sealed lead acid batteries.
Do not attempt to charge any other type of battery or
any non-rechargeable type of battery.
• DO NOT attempt to use the charger as a DC power source
for any electrical or other equipment.
• DO NOT attempt to charge a frozen battery.
1. Select a clean, dry, cool, well ventilated area to use the charger.
2. If your charger is equipped with an off button, ensure that the
charger is in the OFF position, along with the joystick controller
in the OFF position.
3. Connect the charger output cord into the charger port located on
the front of the joystick controller. Refer to Figure 2A below. Align the
three pins on the plug with the three holes on the port and push the
plug in place. Make sure the plug is fully seated in the charger port.
If it is not pushed all the way, the batteries will not charge or the plug
may become hot.
Figure 2A - Charger Port, Typical Location
