D82008753R 10/15 Chapter 4 35
Locking the Seat Back
The seat back will fold forward when pushed from the rear or pulled from
the front (Figure 4Q). If you prefer to have the seat back locked into
place and stationary; screws and a hex key have been provided with
your Hoveround to lock the seat back.
Figure 4Q
Figure 4R Figure 4S Figure 4T
1. Locate the holes on each side of the seat back frame above the
angle adjustment hinge. (Figure 4R)
2. Insert the button head cap screws, one each side of the seat back.
Tighten with the 5/32" hex key. (Figures 4S and 4T)
