Arm Width Adjustment
The standard seat has arm width adjustment (Figure 4F and 4G). To adjust
the arm width:
1. Locate the two knobs and two set screws on the square tube at the
rear of the seat.
2. Loosen the knobs and set screws.
3. Move the arms to a comfortable width. Make sure the tubes do not
extend beyond the set screws.
4. Tighten the knobs and set screw.
Figure 4F
Figure 4G
Arm Height Adjustment
If arm height adjustment is required an arm raising or arm lowering kit is
available (Figure 4H). To adjust the arm height:
1. Locate the set screw on the back of the arm tube upright.
2. Loosen the screw and adjust the arm to a comfortable height.
3. Tighten the screw.
Figure 4H
