38 Chapter 5 D82008753R 10/15
Optional Power Seat Lift (PSL)
To reduce chance of serious injury or death due to a fall from
the seat, do not operate optional power seat lift unless you are
on a flat, hard, level surface.
Driving with the seatback reclined makes it difficult to see where
you are going and increases the chance of serious injury or
death from collision and tip-over. Do not attempt to drive this
vehicle with seatback reclined.
Press either seat symbol button to activate the PSL mode (see Figure 5A
below). When the indicator light is lit, move the joystick forward to raise
the seat, back to lower. The MPV5
®
will not drive while seat is raised and
light is on. When seat is fully down, press either button to restore drive
mode. Your power wheelchair contains a lock-out feature that prevents
driving when the seat is in the raised position.
Indicator Light
Seat Symbol Buttons
Figure 5A
Optional Reclining Back Seat
The optional reclining seat will permit the seatback to recline approximately
45 degrees.
