32 Chapter 4 D82007778Q 09/15
Seat Back Angle Adjustment
The seat back has fixed positions to select from (Figure 4I).
To change the back angle position:
1. Locate the screw and nut on the left hinge and right hinge.
2. Remove the screw and nut and place the back in the desired angle
position. Make sure the holes in the outer hinge and inner hinge
brackets line up for the desired angle.
3. Re-install the screws and nuts into the new location and tighten
securely.
Figure 4I
The seat back will fold forward when pushed from the rear or
pulled from the front. Always use caution when pushing from
the rear or leaning on the seat back as it may cause the user
to fall, resulting in serious injury or death. If the chair must be
pushed from the back, push or pull on the arms or another
solid surface.
