Hoveround Teknique XHD - Chapter 5 Anti-Tip Wheels

36 Chapter 5 D82007778Q 09/15
Chapter 5
Anti-Tip Wheels
Mounted to the front or rear of the frame, anti-tip wheels protect against
the unit tipping in the unlikely event of an abrupt stop or start (See Figure
5A below).
Figure 5A
RWD and GT
Anti-Tip Wheels
(Rear Wheel Drive Shown)
Figure 5A
FWD, XHD and HD-6
Anti-Tip Wheels
(Front Wheel Drive Shown)
Do not remove Anti-Tip wheels.
