5–48 Maintenance and Service Guide
Removal and Replacement Procedures
3. Remove the five Phillips PM2.0×3.0 screws 1 that secure the
TouchPad bracket to the top cover.
4. Remove the TouchPad bracket 2 and TouchPad board 3
from the top cover.
✎
When removing the TouchPad bracket and TouchPad board,
make note of the location of the TouchPad button actuators 4.
Removing the TouchPad
