Removal and Replacement Procedures
Maintenance and Service Guide 5–49
5. Remove the two Phillips PM2.0×2.0 screws 1 that secure the
TouchPad board to the TouchPad bracket.
6. Remove the TouchPad board 2 from the TouchPad bracket.
Removing the TouchPad Board
Reverse the above procedure to install the TouchPad.
