Removal and Replacement Procedures
Maintenance and Service Guide 5–79
❏ Keyboard (Section 5.10)
❏ Switch cover (Section 5.11)
❏ Display assembly (Section 5.12)
❏ Top cover (Section 5.13)
❏ Wireless switch board (Section 5.15)
❏ Audio/infrared board (Section 5.17)
❏ Bluetooth module (Section 5.18)
❏ USB board (Section 5.19)
❏ System board (Section 5.21)
❏ Fan/heat sink assembly (Section 5.23)
✎
Steps 2 and 3 apply only to computer models using
Intel processors.
