Table 3-2 Display components and their descriptions (continued)
Item Component Spare part number
FHD, antiglare, 250 nits L61945-001
FHD, BrightView, 250 nits L61946-001
HD, antiglare, 220 nits L61947-001
HD, BrightView, 220 nits L61948-001
HD, BrightView, 220 nits, Touch-on Panel (TOP) L61949-001
(4) Display panel cable (includes bezel adhesive tape):
For use with touch displays L64908-001
For use with non-touch displays L64909-001
(5) Webcam/microphone module (includes bezel adhesive tape) L64914-001
(6) Display hinges (left and right; includes bezel and display cover adhesive) L64910-001
(7) Wireless antennas (includes bezel adhesive tape and display cover tape):
Dual antennas L64905-001
Single antenna L64906-001
(8) Display back cover (includes bezel adhesive tape):
Natural silver L66227-001
Pale gold L66228-001
Snowake white L66229-001
18 Chapter 3 Illustrated parts catalog
