Logic Analyzer
Pod
High-density
Adapter Cable
Shroud
The HP E5346A high-density adapter provides a convenient and easy way to connect an HP
logic analyzer to the signals on your target system for packages that are difficult to probe, such
as BGAs. An Amp "Mictor 38" connector must be installed on your target system board.
16allp29
29
Probing
Probing
High Density Adapter
HP Logic Analyzer Modules
E5346A (With Tip RC Network)
Tip RC Network
Equivalent Load
10pF
250
ohm
370
ohm
90.9k
ohm
Signal Signal
To Logic
Analyzer
Pod
Ground Ground
Includes logic analyzer
9pF3pF
100k
ohm
Amp "Mictor 38"
Connector
AMP "Mictor 38" Connector Pinout
(Top View)
Even Pod
+5VDC
GND DC
CLK
D15
D14
D13
D12
D11
D10
D9
D8
D7
D6
D5
D4
D3
D2
D1
D0
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
Odd Pod
SCL
SDA
CLK
D15
D14
D13
D12
D11
D10
D9
D8
D7
D6
D5
D4
D3
D2
D1
D0
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
