HP 16600A Series User Manual

The HP E5351A high-density adapter provides a convenient and easy way to connect an HP
logic analyzer to the signals on your target system for packages that are difficult to probe, such
as BGAs. The proper RC networks and an AMP "Mictor 38" connector must be installed on
your target system board. See Application Note: Probing Solutions for HP Logic Analysis
Systems.
16allp30
30
Probing
Probing
High Density Adapter
HP Logic Analyzer Modules
Logic Analyzer
Pod
High-density
Adapter Cable
Shroud
Amp "Mictor 38"
Connector
E5351A (No Tip Network)
Suggested On Board RC Network
10pF
250
ohm
90.9k
ohm
Signal
To
High Density
Adapter Cable
Ground
Must be terminated on-board.
Equivalent Load
370
ohm
Signal
Ground
Includes on board RC network and logic analyzer
9pF0.3pF
100k
ohm
HP E5351A High Density
Adapter Cable
To Logic
Analyzer
Pod
AMP "Mictor 38" Connector Pinout
(Top View)
Even Pod
+5VDC
GND DC
CLK
D15
D14
D13
D12
D11
D10
D9
D8
D7
D6
D5
D4
D3
D2
D1
D0
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
Odd Pod
SCL
SDA
CLK
D15
D14
D13
D12
D11
D10
D9
D8
D7
D6
D5
D4
D3
D2
D1
D0
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
