HP 1810-24G User Manual

Table 2 System Description Fields (continued)
DescriptionField
Component from which the massage was logged.Component
Description of the entry.Description
For information on configuring log settings, see “Log Configuration” (page 54).
Port Summary page
The Port Summary page displays a summary of network traffic from the ports. This summary can
be used to identify potential problems with the switch. It also helps to identify what has been
configured on this port. The displayed values are accumulated after the last clear operation.
Refreshing the page shows the latest statistics, which provide per-port statistics on packets transmitted
and received for all the ports. Scroll down the page to view the Port Statistics table, which provides
per-port statistics on packets transmitted and received.
To display the Port Summary page, click Status > Port Summary in the navigation pane.
A configuration summary and status of all physical and logical ports are displayed in Figure 6.
Figure 6 Port Summary Page
14 Status Pages

HP 1810-24G Specifications

General

Switching Capacity	52 Gbps
Throughput	38.7 Mpps
Form Factor	Rack-mountable
Management	Web-based GUI
Power Supply	Internal
Layer	Layer 2
Operating Temperature	0°C to 40°C (32°F to 104°F)
Ports	24 RJ-45 10/100/1000 ports
Weight	2.27 kg (5.0 lb)
Operating Humidity	10% to 90% non-condensing
