HP 1810-24G User Manual

Figure 9 MAC Table Page
Table 6 MAC Table Fields
DescriptionField
Displays a maximum of 8192 MAC address entries that can be learned on the switch.Maximum Entries Supported
Displays the number of MAC address entries currently learned.Current Entries
The list of MAC addresses learned on a particular interface.MAC Address
The source interface on which the particular MAC address has been learned.Source Port
CPU is a special source port used for internal management on the switch.
Shows whether the MAC address is dynamically learned or whether this is a management
address.
MAC Type
Click the Refresh link above the page to re-display the page with current data from the switch.
Loop Protection Status page
The Loop Protection Status page displays a summary of loop protection configured data on the
switch and on each port, and loop protection network traffic for the switch and status information
for each port.
To display the Loop Protection status page, click Status > Loop Protection in the navigation pane.
Figure 10 Loop Protection Page
18 Status Pages

HP 1810-24G Specifications

General

Switching Capacity	52 Gbps
Throughput	38.7 Mpps
Form Factor	Rack-mountable
Management	Web-based GUI
Power Supply	Internal
Layer	Layer 2
Operating Temperature	0°C to 40°C (32°F to 104°F)
Ports	24 RJ-45 10/100/1000 ports
Weight	2.27 kg (5.0 lb)
Operating Humidity	10% to 90% non-condensing
