HP 1920 Series - 1920-24 G-Poe+ (180 W); 1920-24 G-Poe+ (370 W)

22
Figure 30 1920-8G-PoE+ (180W) rear panel
(1)
A
C power receptacle (2)
Groundin
g
screw
(3) Security slot
1920-24G-PoE+ (180W)
Figure 31 1920-24G-PoE+ (180W) front panel
(1) 10/100/1000BASE-T copper ports
(2)
100/1000BASE-X SFP fiber ports
(3) Fiber port LEDs (4) Copper port LEDs
(5) Power LED (6) Console port
Figure 32 1920-24G-PoE+ (180W) rear panel
(1) Groundin
g
screw (2)
A
C power receptacle
1920-24G-PoE+ (370W)
Figure 33 1920-24G-PoE+ (370W) front panel
(1) 10/100/1000BASE-T copper ports (2) 100/1000BASE-X SFP fiber ports
(3) Fiber port LEDs
(4) Copper port LEDs
(5) Redundant power system (RPS) power LED
(6)
Power LED
(7) Console port
21 3
