Figure 34 1920-24G-PoE+ (370W) rear panel
(1) Groundin
g
screw (2)
A
C power receptacle
(3) DC power receptacle
1920-48G-PoE+ (370W)
Figure 35 1920-48G-PoE+ (370W) front panel
(1) Copper port LED switching button (2) Copper port mode LED
(3) RPS power LED
(4)
Power LED
(5) Console port (6)
100/1000BASE-X SFP fiber ports
(7) 10/100/1000BASE-T copper ports
Figure 36 1920-48G-PoE+ (370W) rear panel
(1) DC power receptacle (2)
A
C power receptacle
(3) Grounding screw
Physical specifications
Chassis dimensions and weights
Chassis Dimensions (H x W x D)
Maximum
w
ei
g
ht
1920-8G 44 x 266 x 162 mm (1.73 x 10.47 x 6.38 in) 1 kg (2.20 lb)
1920-16G 44 x 440 x 173 mm (1.73 x 17.32 x 6.81 in) 2.1 kg (4.63 lb)
