Introduction
1-4 HP 1U Integrated Keyboard Drawer User Guide
CONFIDENTIAL
Writer: John Turner - Amy Laffitte File Name: b-ch1 Introduction
Codename: Dachshund Part Number: 269450-001 Last Saved On: 7/29/02 1:20 PM
11
12
14
15
13
PROGRAM 1 2 3 4 5 6 7 8 9
5 6 7 8 9 10
Figure 1-3: Components of the keyboard
Table 1-3: Components of the keyboard
5 Programmable wizard key Initiates the programming operations
mode, allows programming of nine
hot keys, and returns the hot keys to
defaults
6 Nine hot keys Allows quick access to the nine most
often used devices
7 Keyboard hot key label
(user installed)
Allows the user to record
programmed hot keys
8 Number lock LED
9 Cap lock LED
10 Scroll lock LED
11 Track ball
continued
