FHD panels:
b. Pull the tape out from behind the left and right sides of the panel.
NOTE: You have to pull on the tape multiple times before it is completely removed.
Display panel stretchable adhesive tape is available using spare part number L29080-001.
c. HD and FHD panels:
Swing the top edge of the display panel forward and position it upside down next to the display
enclosure (1).
d. Release the adhesive support strip (2) that secures the display panel cable connector to the
display panel.
e. Disconnect the display panel cable (3) from the display panel.
f. Remove the display panel.
Raw display panels are available using the following spare part numbers:
L50021-001: HD
Component replacement procedures 57
