M.2 solid-state drive
Description
32 GB solid-state drive (SSD), M.2, 2242DS
The M.2 SSD is secured with one Phillips screw. It is located under the drive cage.
To remove the M.2 SSD:
1. Prepare the computer for disassembly (
Preparation for disassembly on page 17).
2. Remove the access panel (
Access panel on page 18).
3. Remove the hard drive (
Hard drive on page 19).
4. Remove the drive cage (
Drive cage and drive cable on page 32).
5. Remove the Phillips screw that secures the module to the computer.
M.2 solid-state drive 37
