HP 33120A User Guide

To generate a phase unlock error
You can configure the function generator to generate an error condition
whenever phase lock is lost. The following steps show you how to enable
an unlock error.
1 Turn on the menu.
A: MOD MENU
2 Move across to the
PHASE MENU choice on this level.
G:PHASE MENU
3 Move down a level and then across to the
UNLOCK ERR command.
4:UNLOCK ERR
4 Move down a level and enable the unlock error.
ENABLE
5 Save the change and turn off the menu.
The unlock error setting is stored in non-volatile memory, and does not
change when power has been off or after a remote-interface reset.
See also “The
SCPI Status Registers” on page 23.
∨
Enter
Menu On/Off
Shift
<
∨
<
Chapter 1 Quick Start
To generate a phase unlock error
14

HP 33120A Specifications

General

Frequency Range	100 µHz to 15 MHz
Waveforms	Sine, Square, Triangle, Ramp, Arbitrary
Amplitude Range	10 mVpp to 10 Vpp into 50 Ohms
Output Impedance	50 Ohms
Interface	GPIB
Function Generator Type	Arbitrary
Power Requirements	100/120/220/240 VAC ±10%, 50/60 Hz, 60 VA max
