HP 33120A User Guide

The SCPI Status Registers
The function generator uses the Status Byte, the Standard Event,
and the Questionable Data register groups (phase-lock assembly only)
to record various instrument conditions. This section discusses only the
Questionable Data register group; refer to chapter 4 in the HP 33120A
User’s Guide for a complete discussion of the status registers. A diagram
of the
SCPI status system is shown on the next page.
An example program is included in chapter 6, “Application Programs,”
of the HP 33120A User’s Guide which shows the use of the status registers.
You may find it useful to refer to the program after reading the following
section in this chapter.
2
Chapter 2 Remote Interface Operation
The SCPI Status Registers
23

HP 33120A Specifications

General

Frequency Range	100 µHz to 15 MHz
Waveforms	Sine, Square, Triangle, Ramp, Arbitrary
Amplitude Range	10 mVpp to 10 Vpp into 50 Ohms
Output Impedance	50 Ohms
Interface	GPIB
Function Generator Type	Arbitrary
Power Requirements	100/120/220/240 VAC ±10%, 50/60 Hz, 60 VA max
