HP 33120A User Guide

2 Turn on the menu.
A: MOD MENU
3 Move across to the
PHASE MENU choice on this level.
G:PHASE MENU
4 Move down a level to the
ADJUST command.
1: ADJUST
5 Move down a level and set the phase offset.
You can set the offset to any value between -360 degrees and +360 degrees.
The displayed phase is output “real time” unless you have selected the
arbitrary waveform function.
∧000.000 DEG
6 Turn off the menu.
The function generator beeps and displays a message. You are then
exited from the menu.
At this point, the function generator is phase-locked to the external clock
signal with the specified phase relationship. The two signals will
remain locked unless you change the function or output frequency.
∨
Enter
<
∨
Menu On/Off
Shift
Chapter 1 Quick Start
To phase lock to an external clock signal
6

HP 33120A Specifications

General

Frequency Range	100 µHz to 15 MHz
Waveforms	Sine, Square, Triangle, Ramp, Arbitrary
Amplitude Range	10 mVpp to 10 Vpp into 50 Ohms
Output Impedance	50 Ohms
Interface	GPIB
Function Generator Type	Arbitrary
Power Requirements	100/120/220/240 VAC ±10%, 50/60 Hz, 60 VA max
