NOTE: The following image shows the display panel connected to the computer. It will not be
connected in this procedure.
b. Rotate the display panel o the display enclosure (1) to gain access to the display cable connection
on the back of the panel.
c. On the back of the display panel, release the adhesive strip (2) that secures the display panel cable
to the display panel, and then disconnect the cable (3).
NOTE: The following image shows the display panel connected to the computer. It will not be
connected in this procedure.
4. To remove the display hinges:
Component replacement procedures 61
