To Select the Remote Interface
The multimeter is shipped with both an HP-IB (IEEE-488) interface
and an
RS-232 interface. Only one interface can be enabled at a time.
The
HP-IB interface is selected when the multimeter is shipped from
the factory. See also “Remote Interface Selection,” on page 92.
1 Turn on the front-panel menu.
A: MEAS MENU
2 Move across to the
I/O MENU choice on this level.
E: I/O MENU
3 Move down a level and then across to the
INTERFACE command.
2: INTERFACE
4 Move down to the “parameter” level to select the interface.
Use the left/right arrow keys to see the interface choices. Choose from
the following:
HP-IB / 488 or RS-232.
HP-IB / 488
5 Save the change and turn off the menu.
The interface selection is stored in non-volatile memory, and does not
change when power has been off or after a remote interface reset.
<
<
Shift <
On/Off
Auto/Man
ENTER
∨
∨
>
Chapter 4 Remote Interface Reference
To Select the Remote Interface
162
