• Front-Panel Operation: First, select the ac current (or ac voltage)
function on the active channel. Then, go to the Advanced menu and
select the slow filter (3 Hz), medium filter (
20 Hz), or fast filter
(200 Hz) for the active channel. The default is the medium filter.
LF 3 HZ:SLOW
• Remote Interface Operation: Specify the lowest frequency expected in
the input signal on the specified channels. The instrument selects the
appropriate filter based on the frequency you specify (see table on
previous page). The MEASure? and CONFigure commands
automatically select the 20 Hz (medium) filter.
SENS:CURR:AC:BAND 3,(
@221) Select the slow filter (3 Hz)
4
Chapter 4 Features and Functions
Current Measurement Configuration
117
