CONFigure Command Syntax
CONFigure:TEMPerature
{TCouple},{B|E|J|K|N|R|S|T|DEF}
[,1[,<
resolution>|MIN|MAX|DEF}]] ,(@<scan_list>)
Configure the specified channels for thermocouple measurements but
do not initiate the scan. Note that this command also redefines the scan list.
The default (DEF) transducer type is a J-Type thermocouple.
CONFigure:TEMPerature
{RTD|FRTD},{85|91|DEF}
[,1[,<
resolution>|MIN|MAX|DEF}]] ,(@<scan_list>)
Configure the specified channels for 2-wire or 4-wire
RTD measurements
but do not initiate the scan. Use “85” to specify
α = 0.00385 or “91” to
specify
α = 0.00391. Note that this command also redefines the scan list.
The default (
DEF) type is “85” (α = 0.00385).
For 4-wire
RTD measurements (FRTD), the instrument automatically
pairs channel n with channel n+10 (34901A) or n+8 (34902A) to provide
the source and sense connections. For example, make the source
connections to the
HI and LO terminals on channel 2 and the sense
connections to the
HI and LO terminals on channel 12. Specify the
paired channel in the lower bank (source) as the scan_list channel.
CONFigure:TEMPerature
{THERmistor},{2252|5000|10000|DEF}
[,1[,<
resolution>|MIN|MAX|DEF}]] ,(@<scan_list>)
Configure the specified channels for thermistor measurements but
do not initiate the scan. Note that this command also redefines the scan list.
The default (DEF) transducer type is a 5 k
Ω thermistor.
5
Chapter 5 Remote Interface Reference
The MEASure? and CONFigure Commands
211
