CONFigure:FREQuency

CONFigure:PERiod

[{<

range>|AUTO|MIN|MAX|DEF}

[,<

resolution>|MIN|MAX|DEF}],] (@<scan_list>)

Configure the specified channels for frequency or period measurements

but do not initiate the scan. Note that this command also redefines the

scan list.

CONFigure:DIGital:BYTE (

@<scan_list>)

Configure the instrument to read the specified digital input channels

on the multifunction module but do not initiate the scan. Note that this

command also redefines the scan list. The digital input channels are

numbered “s01” (

LSB) and “s02” (MSB), where s is the slot number.

Note that if you include both digital input channels in the scan list,

the instrument will read data from both ports simultaneously with the

same time stamp. This will allow you to externally combine the two

8-bit value into one 16-bit value.

CONFigure:TOTalize {READ|RRESet} ,(

@<scan_list>)

Configure the instrument to read the specified totalizer channels on the

multifunction module but do not initiate the scan. Note that this command

also redefines the scan list. The totalizer channel is numbered “s03”,

where s represents the slot number.

To read the totalizer during the scan without resetting the count, select

the READ parameter. To read the totalizer during the scan and reset the

count to “0” after it is read, select the RRESet parameter (this means

“read and reset”).

CONFigure? [(

@<ch_list>)]

Query the present configuration on the specified channels and return a

series of quoted strings. If you omit the optional ch_list parameter,

the instrument uses the active scan list. The command returns a series

of comma-separated fields as shown in the example below. Each field

contains the function, range, and resolution.

"FRES +1.000000E+02,+3.000000E-04" , "TEMP TC,K,+1.000000E+00,+3.000000E-06"

Chapter 5 Remote Interface Reference

The MEASure? and CONFigure Commands

213

HP 34970A User Manual
