RS-232 Interface Configuration
See also “Remote Interface Configuration” in chapter 4 on page 150.
This section contains information to help you use the instrument over
the RS-232 interface. The programming commands for RS-232 are listed
on page 269.
RS-232 Configuration Overview
Configure the RS-232 interface using the parameters shown below.
Use the front-panel Interface menu to select the baud rate, parity,
number of data bits, and flow control mode (see page 152 for more
information).
• Baud Rate: 1200, 2400, 4800, 9600, 19200, 38400,
57600 (factory setting), 115200
• Parity and Data Bits:
None / 8 data bits (factory setting)
Even / 7 data bits
Odd / 7 data bits
• Flow Control: None (no flow control)
XON/XOFF (factory setting)
DTR/DSR
RTS/CTS
Modem
• Number of Start Bits:
1 bit (fixed)
• Number of Stop Bits:
1 bit (fixed)
Chapter 5 Remote Interface Reference
RS-232 Interface Configuration
270
