Front-Panel Overview
This chapter introduces you to the front-panel keys and menu operation.
This chapter does not give a detailed description of every front-panel
key or menu operation. It does, however, give you a good overview of the
front-panel menu and many front-panel operations. See chapter 4
“Features and Functions,” starting on page 71, for a complete discussion
of the instrument’s capabilities and operation.
This chapter is divided into the following sections:
• Front-Panel Menu Reference, on page 35
• To Monitor a Single Channel, on page 37
• To Set a Scan Interval, on page 38
• To Apply Mx+B Scaling to Measurements, on page 39
• To Configure Alarm Limits, on page 40
• To Read a Digital Input Port, on page 42
• To Write to a Digital Output Port, on page 43
• To Read the Totalizer Count, on page 44
• To Output a DC Voltage, on page 45
• To Configure the Remote Interface, on page 46
• To Store the Instrument State, on page 48
34
