Bottom
Component Description
(1)
Battery cover release latch and lock Releases the battery cover over the battery bay.
(2) Battery bay Holds the battery.
(3) Keyboard screw Allows removal of the keyboard.
(4)
Memory service cover Provides access to the keyboard screw, memory
module slots, and optical drive.
(5) Vents (4) Enable airflow to cool internal components.
Bottom 11
