HP 37718A User Manual

3-97
Performance Tests
PDH Transmit/Receive Jitter Amplitude Accuracy
Check the Received Jitter Accuracy is within the limits in Table 3-5.
24 Return the TX MODULATION SOURCE to INTERNAL.
25 Check the Jitter accuracy for each value in Table 3-5. In each case, set the HP
37718A Rate and Spectrum Analyzer Center Frequency to the value given in
column 1 of the table (Set the HP 37718A PATTERN to ALL ONES and the
JITTER AMPLITUDE to minimum after each change of Bit Rate). Set the
HP 37718A Jitter Modulation Frequency and Amplitude to the values given in
columns 2 and 3 of the table. Fine-tune the amplitude to obtain the lowest carrier
level on the Spectrum Analyzer display and check that the TX jitter amplitude
displayed on the HP 37718A is between the limits given in columns 4 and 5 of
Table 3-5.
Table 3-5 Range 10/16 Tx/Rx Jitter Amplitude Accuracy
Bit Rate/
Center
Frequency
Modulation
Frequency
Nulled Jitter
Amplitude (UI)
Minimum
Jitter (UI)
TX
Maximum
Jitter (UI)
TX
Minimum
Jitter (UI)
RX
Maximum
Jitter (UI)
RX
2048kHz 2400Hz 1.8 1.5 2.0 1.587 1.933
2048kHz 2400Hz 4.8 4.4 5.1 4.377 5.143
2048kHz 2400Hz 8.8 8.2 9.3 8.097 9.423
8448kHz 10700Hz 1.8 1.5 2.0 1.587 1.933
8448kHz 10700Hz 5.8 5.3 6.2 5.307 6.213
8448kHz 10700Hz 8.8 8.2 9.3 8.097 9.423
34368kHz 4000Hz 2.8 2.5 3.0 2.517 3.003
34368kHz 4000Hz 6.8 6.2 7.3 6.237 7.283
34368kHz 4000Hz 8.8 8.2 9.3 8.097 9.423
139264kHz 4000Hz 3.8 3.3 4.2 3.447 4.073
139264kHz 4000Hz 7.8 7.1 8.4 7.167 8.353
139264kHz 4000Hz 8.8 8.1 9.4 8.097 9.423
