HP 37718A User Manual

3-131
Performance Tests
Jitter Performance Test Record (options 204, 205 & 206)
Jitter Performance Test Record (options 204, 205 & 206)
Hewlett-Packard Model 37718A 2.5 Gb/s Multirate Communications
Performance Analyzer (Jitter options only)
Location: Serial No.:
Tested by: Options:
Temperature: Certified by:
Humidity: Date:
Table 7 Performance Test Record
Page
No.
Test Description Result
Min Actual Max
3-89 PDH Tx/Rx Jitter Amplitude
Accuracy
Step 8 AIS LED On Pass/Fail
Step 12 2048 kHz - Tx 0.69 UI 0.83
Step 12 2048 kHz - Rx 0.711 UI 0.829 UI
Step 12 8448 kHz - Tx 0.69 UI 0.83 UI
Step 12 8448 kHz - Rx 0.706 UI 0.834 UI
Step 12 34368 kHz - Tx 0.69 UI 0.83 UI
Step 12 34368 kHz - Rx 0.706 UI 0.834 UI
Step 12 139264 kHz - Tx 0.68 UI 0.84 UI
Step 12 139264 kHz - Rx 0.706 UI 0.834 UI
Step 19 AIS LED On Pass/Fail
Step 22 2048 kHz - Null 1.8 UI Tx 1.5 UI Tx 2.0 UI
2048 kHz - Null 1.8 U Rx 1.587 UI Rx 1.933 UI
2048 kHz - Null 4.8 UI Tx 4.4 UI Tx 5.1 UI
