HP 37718A - JITTER Test (Test Time- Approximately 20 Minutes)

5-6
Installation
Self Tests
JITTER Test (test time- approximately 20 minutes)
These tests apply to HP 37718A option 204, 205, 206 only. Provides extensive tests
of the PDH/SDH Tx/Rx Jitter sections. Note this test is run as part of ALL TESTS.
Subtest Test Function
1-50 Jitter Receiver Internal Loopback tests
51-100 Not used
101 STM-16 Optical Power Check
102 Not used
103-108 2Mb/s Tx/Rx Jitter Tests
109-114 8Mb/s Tx/Rx Jitter Tests
115-120 34Mb/s Tx/Rx Jitter Tests
121-126 140Mb/s Tx/Rx Jitter Tests
127-150 Not used
151-156 STM1e Tx/Rx Jitter Tests
157-162 STM1o Tx/Rx Jitter Tests
163-168 STM-4 Tx/Rx Jitter Tests
169-174 STM-16 Tx/Rx Jitter Tests
175-177 Wander Tests
178 Transfer Test 155 Electrical
179 Transfer Test STM-16
LONG GATING test (test time- approximately 6 Hours)
This test performs an extended gating check of each SDH/SONET Optical rate to
confirm error free operation. Test time at each rate is sufficient to ensure that the
error ratio is less than 1 in 10^12. The test does NOT form part of ALL TESTS.
Subtest Test Function
1 Tx/Rx STM-0o with Bulk 2^23 Payload
2 Tx/Rx STM-1o with Bulk 2^23 Payload
3 Tx/Rx STM-4o with Bulk 2^23 Payload
4 Tx/Rx STM-16o with Bulk 2^23 Payload
