3-116
Performance Tests
SDH Transmit/Receive Jitter Amplitude Accuracy
STM-16 Optical
50 .Change Transmit/Receive Rate to STM-16 Optical with AU4-16C Mapped Bulk
Filled 2^23 PRBS Payload. Check and adjust the optical power as necessary.
Ensure Jitter is OFF and Calibration Pattern is OFF, then repeat steps 6 to 43
using the information in the Table below for STM-16.
51 In the case of dual wavelength option units set to the alternative wavelength
(1550nm) and repeat steps 6-9 for each rate.
STEP TX
Range
RX
Range
RX
Filter
Tx
UI p-p
Tx
Freq
TX Result
MIN p-p
TX Result
MAX p-p
RX Result
MIN p-p
RX Result
MAX p-p
6-8 OFF 1.6UI LP+HP2 OFF OFF OFF OFF N/A 0.070
9 OFF 1.6UI LP+HP1 OFF OFF OFF OFF N/A 0.070
13-15 20 1.6UI LP+HP1 0.2 1M 0.14 0.26 0.114 0.286
16-20 LP+HP2 10 M 0.13 0.27 0.100 0.300
22-25 LP+HP1 0.91 100K 0.81 1.01 0.795 1.026
27-31 64UI 3.52 50K 3.29 3.75 3.124 3.916
33-37 9.52 25K 8.99 10.05 8.53 10.34
39-43 800 1024 FIXED 528 50Hz 499.60 556.40 451.60 604.40
