Performance Tests
Jitter Performance Test Record (options 204, 205 & 206)
3-101
SDH Tx/Rx Jitter Amplitude
Accuracy
STM1 Electrical
Step 8
No SDH result errors
Pass/Fail
Step 8
Jitter result
<0.050 UI p-p
Step 9: Jitter result <0.050 UI p-p
Step 14: No SDH errors Pass/Fail
Step 15: Tx Jitter results 0.06 UI p-p 0.14 UI p-p
Rx Jitter results 0.043 UI p-p 0.157 UI p-p
Step 19 No SDH errors Pass/Fail
Step 20 Tx results 0.06 UI p-p 0.14 UI p-p
Rx Jitter results 0.042 UI p-p 0.158 UI p-p
Step 24 No SDH errors Pass/Fail
Step 25 Tx Jiter results 0.82UI p-p 1.00 UI p-p
Rx Jitter results 0.796 UI p-p 1.024 UI p-p
Step 30 No SDH errors Pass/Fail
Step 31 Tx Jitter results 3.30 UI p-p 3.74 UI p-p
Rx Jitter Results 3.204 UI p-p 3.836 UI p-p
Step 35 No SDH errors Pass/Fail
Step 36 Tx Jitter results 7.10 UI p-p 7.94 UI p-p
Rx Jitter results 6.756 UI p-p 8.164 UI p-p
Step 41 No SDH errors Pass/Fail
Step 42 Tx Jitter result 30.82 UI p-p 35.18 UI p-p
Rx Jitter result 28.350 UI p-p 37.650 UI p-p
Table 7 Performance Test Record continued
Page
No.
Test Description Result
Min Actual Max
To Next Page
