iv
Contents
Connecting to the Power Supply 2-4
Connecting to the Network 2-6
All Connectors 2-6
Electrical Interface Connectors 2-6
Optical Interface Connectors 2-9
Connecting Accessories 2-11
10 Base-T Lan Connection Radiated Emissions 2-11
Hewlett-Packard Interface Bus 2-12
Additional Precautions for Service Engineers 2-14
Safety Precautions 2-14
ESD Precautions 2-14
Front Panel Soft Recovery (Cold Start) 2-16
3 Performance Tests
Introduction 3-1
Equipment Required 3-1
Performance Test Record 3-1
Calibration Cycle 3-1
Option Configuration 3-1
Recall Default Settings 3-4
Self Test 3-5
PDH/DSn Internal Transmitter Clock Accuracy & Offset 3-10
Specifications 3-10
Equipment Required 3-10
E1 (2.048Mb/s) Frequency Accuracy 3-11
E2 (8.448Mb/s) Frequency Accuracy 3-12
E3 (34.368Mb/s) Frequency Accuracy 3-12
E4 (139.264Mb/s) Frequency Accuracy 3-13
DS1 (1.544Mb/s) Frequency Accuracy 3-13
DS3 (44.736Mb/s) Frequency Accuracy 3-14
PDH/DSn Transmitter Output 3-15
