3-34
P
erformance T
ests
PDH/DSn Receiver Equalization
34.368 Mb/s
8
Set the
display as shown below
.
9
Connect
Cable
Simulator
E3
between
PDH/DSn
75
Ω
OUT
and
75
Ω
IN
ports.
10
Press
then
to start the
measurement.
11
Ensure
that
NO
TROUBLE
is
displayed
on
the
display
after
30 seconds.
12
Press
to stop the measurement.
TRANSMIT
RESUL
TS
TROUBLE
SCAN
RUN/ST
OP
RESUL
TS
RUN/ST
OP
