Page #30 background image
26
Appendix B Ports and LEDs
Ports
Console port
Every HP 6125 blade switch has one console port.
Table 6 Console port specifications
Item Specification
Connector type
RJ-45
Compliant standard
EIA/TIA-232
Transmission baud rate 9600 bps (default) to 115200 bps
Services
Provides connection to an ASCII terminal.
Provides connection to the serial port of a local PC or a remote terminal running
terminal emulation program.
10/100/1000Base-T Ethernet port
Every HP 6125 blade switch has 10/100/1000Base-T Ethernet ports.
Table 7 10/100/1000Base-T Ethernet port specifications
Item Specification
Connector type
RJ-45
Interface attributes
10 Mbps, full duplex
100 Mbps, full duplex
1000 Mbps, full duplex
MDI/MDI-X, auto-sensing
Max transmission
distance
100 m (328.08 ft)
Transmission medium
Category-5 (or above) twisted pair cable
Standards
IEEE 802.3i, 802.3u, 802.3ab
IRF/SFP port and SFP port
An HP 6125G has up to four SFP ports. The IRF/SFP ports can be configured for IRF operation, in which
case they will operate as SFP+ ports that will accept supported SFP+ modules or cables (see Table 9
and Table 10)
. If one or both of these ports are not used for IRF, they can be used only as SFP ports that
will accept supported 1000 Mbps SFP transceiver modules (see Table 8), with the exception of HP X1
20
