HP 6125G Installation Guide

27
1G SFP RJ45 T transceiver. The SFP ports will accept all supported 1000 Mbps SFP transceiver modules
including HP X120 1G SFP RJ45 T transceiver.
Table 8 1000 Mbps SFP transceiver modules
Product
code
Module description
Central
wavelength
(nm)
Fiber
diameter
(μm)
Multimode
fiber modal
bandwidth
(MHz
× km)
Max
transmission
distance
JD118B
HP X120 1G SFP LC SX
Transceiver
850
50/125
500
550 m (1804.46
ft)
400
500 m (1640.42
ft)
62.5/125
200
275 m (902.23
ft)
160
220 m (721.78
ft)
JD119B
HP X120 1G SFP LC LX
Transceiver
1310
9/125 N/A
10 km (6.21
miles)
50/125
500
550 m (1804.46
ft)
400
62.5/125 500
550 m (1804.46
ft)
JD061A
HP X125 1G SFP LC LH40
1310nm Transceiver
1310 9/125 N/A
40 km (24.86
miles)
JD062A
HP X120 1G SFP LC LH40
1550nm Transceiver
1550 9/125 N/A
40 km (24.86
miles)
JD063B
HP X125 1G SFP LC LH70
Transceiver
1550 9/125 N/A
70 km (43.50
miles)
JD089B
HP X120 1G SFP RJ45 T
transceiver
N/A
Category-5
twisted pair
N/A
100 m (328.08
ft)
NOTE:
• To guarantee the functionality of the SFP ports, use only HP SFP transceiver modules.
• The SFP transceiver modules available for this blade switch series are subject to chan
g
e over time. For
the most up-to-date list of SFP transceiver modules, consult your HP sales representative or technical
support engineer.
SFP+ port
An HP 6125G/XG has four SFP+ ports. The SFP+ ports can be configured for IRF operation, in which
case they accept supported SFP+ modules or cables. If they are not used for IRF, they accept supported
SFP transceiver modules (with the exception of HP X120 1G SFP RJ45 T transceiver), SFP+ modules, or
SFP+ cables.
