HP b2600

Chapter 3 49
Remove/Replace System Components
Removing/Replacing System Components
8. Slide the CD drive out of the CD drive bay. See Figure 3-14.
Figure 3-14. CD Drive Removed from the CD Drive Bay
CD Drive
Bay
Mounting Screw Holes
CD Drive
Mounting Screw Holes
