Phillips PM2.0×5.0 captive screw
Color Quantity Length Thread Head diameter
Black 5 5.0 mm 2.0mm 5.0 mm
Where used:
(1) Two screws that secure the hard drive cover to the computer (screws are captured on the cover by C-
clips)
(2) One screw that secures the Bluetooth module compartment cover to the computer (screw is captured
on the cover by a C-clip)
(3) One screw that secures the memory module compartment cover to the computer (screw is captured
on the cover by a C-clip)
(4) One screw that secures the WLAN module compartment cover to the computer (screw is captured on
the cover by a C-clip)
110 Chapter 7 Screw listing
