Specifications
Maintenance and Service Guide 6–5
Table 6-4
15.0-inch, XGA, TFT Display
Dimensions
Height
Width
Diagonal
29.9 cm
22.8 cm
38.1 cm
11.8 in
9.0 in
15.0 in
Number of colors Up to 16.8 million
Contrast ratio 150:1
Brightness 150 nits typical
Pixel resolution
Pitch
Format
Configuration
0.264 × 0.264 mm
1280 × 800
RGB vertical stripe
Backlight Edge lit
Character display 80 × 25
Total power
consumption
5.75 W
Viewing angle +/- 35° horizontal, +15/-35° vertical typical
