1–30 Maintenance and Service Guide
Product Description
Table 1-8
Bottom Components
Item Component Function
1 MultiBay Supports an optional MultiBay
device, such as a drive or battery
pack.
2 MultiBay release latch Allows removal of the MultiBay
drive.
3 Bluetooth compartment Holds a Bluetooth device.
✎
Bluetooth is not available
in all countries.
4 Docking connector Connects the notebook to an
optional port replicator.
5 Optical disk drive Reads and records CD and DVD
media.
6 Serial number Identifies the notebook.
You need this number when calling
customer support.
7 Battery pack release latch Releases the primary battery pack
from the battery bay.
8 Battery bay Holds the primary battery pack.
Battery pack ships outside the
notebook.
9 Hard drive cover latch Releases the cover on the hard
drive bay.
10 Hard drive Holds the primary hard drive.
