HP Compaq Business Notebook nc8000 User Manual

Maintenance and Service Guide 3–1
3
Illustrated Parts Catalog
This chapter provides an illustrated parts breakdown and a
reference for spare part numbers and option part numbers.
3.1 Serial Number Location
When ordering parts or requesting information, provide the
notebook serial number and model number located on the bottom
of the notebook.
Serial Number Location

HP Compaq Business Notebook nc8000 Specifications

General

Processor	Intel Pentium M
Display Size	15.0 inches
Operating System	Windows XP Professional
Battery	6-cell Lithium-Ion
Chipset	Intel 855PM
Memory Type	DDR SDRAM
Hard Drive Interface	ATA-100
Storage	40 GB to 80 GB HDD
Display Resolution	1400 x 1050
Graphics	ATI Mobility Radeon 9600
Optical Drive	DVD-ROM
Networking	Intel PRO/Wireless 2200BG
Ports	USB 2.0, VGA, Serial, Parallel
Weight	6.4 lbs (2.9 kg)
